Model No.: HJS-60
Brand: LAN MEI
Support customization: OEM
place of origin: China
Packaging: Export Wooden Packing
Place of Origin: Cangzhou city,He bei province,China
Supply Ability: 20sets/month
HS Code: 8467299000
Port: Tianjin Port,Qingdao Port,Shanghai Port
Payment Type: L/C,T/T,Paypal,Western Union
Delivery Time: 15 Days
60L Mini Electric Laboratory Concrete Mixer Machine
Mixer is mainly composed of retarding mechanism, mixing chamber, worm gear pair, gear, sprocket, chain and bracket, etc.Through the chain transmission, the machine mixing pattern for motor drive axle shaft cone drive, cone by gear and chain wheel drives the stirring shaft rotation, mixing materials.Unloading transmission form for motor through a belt drive reducer, reducer by chain drive stirring the rotate, flip and reset,unload the material.The tectonic type of this machine has been included into national compulsory industry
(1) the machine should be placed in the environment without strong corrosive medium.
(2) After using,clean the interior parts in the mixer tank with clear water.(If don’t use for a long time, can coat rust-proof oil on the mixing chamber and the blade surface)laboratory Pulverizer.(3) before use,should check whether the fastener is loose, in case loose should tighten timely.
(4) When turning on the power supply,should avoid any part of the human body directly or indirectly touch with mixing blades.
(5) mixing motor reducer, chain, and each bearing should regularly or timely fill oil, ensure lubrication, oil is 30 # engine oil.
1. Tectonic Type: Double-horizontal shafts
2. Nominal Capacity: 60L
3. Mixing Motor Power: 3.0KW
4. Discharging Motor Power: 0.75KW
5. Material of work chamber: high quality steel tube
6. Mixing Blade: 40 Manganese Steel (casting)
7. Distance between Blade and inner chamber: 1mm
8. Thickness of work chamber : 10mm
9. Thickness of Blade: 12mm
10. Overall Dimensions: 1100×900×1050mm
11. Weight: about 700kg
12. Packing: wooden case
