Technical Parameters:
1. Tectonic Type: Double-horizontal shafts
2. Output Capacity: 60L ( input capacity is more than 100L)
3.Work voltage:three-phase,380V/50HZ
4. Mixing Motor Power: 3.0KW，55±1r/min
5. Unloading Motor Power: 0.75KW
6. Material of work chamber: high quality steel,10mm thickness.
7. Mixing Blades: 40 Manganese Steel (casting),Thickness of Blade: 12mm
If they wear out, they can be taken down.and replace with new blades.
8.Distance between Blade and inner chamber: 1mm
Big stones cann’t be stuck,if small stones go into the distance can be crushed when mixing.
9.Unloading:Chamber can be stay at any angle,it is convenient for unloading.When chamber turn 180 degrees,then press mixing button,all materials goes down,it is easy for cleaning.
10.Timer: with timer function(factory setting is 60s).within 60 seconds the concrete mixture can be mixed into homogeneous fresh concrete.
11. Overall Dimensions: 1100×900×1050mm
12.Weight: about 700kg
13. Packing: wooden case
