Turkish customer orders 20 sets concrete pressure test machines
Concrete Pressure Testing Machine ,Concrete Compression Testing Machine ,Concrete Pressure Testing Machine
|
Maximum test force: |
2000kN |
Testing machine level: |
1level |
|
Relative error of test force indication: |
±1%within |
Host structure: |
Four column frame type |
|
Piston stroke: |
0-50mm |
Compressed space: |
320mm |
|
Upper pressing plate size: |
240×240mm |
Lower pressing plate size: |
250×350mm |
|
Overall dimensions: |
900×460×1320mm |
Overall power: |
1.0kW(Oil pump motor0.75kW) |
|
Overall weight: |
700kg |
Voltage |
380V/50HZ |
