Product Description
Muffle furnace
Muffle Furnaces are used for high-temperature testing applications such as loss-on-ignition or ashing.Muffle Furnaces are compact countertop heating sources with insulated firebrick walls to maintain high temperatures. The laboratory muffle furnaces offer a range of features including, rugged construction, programmable controllers, and a safety switch that turns off power when the door opens.
Uses:Box-type resistance furnace designed for chemical element analysis, and small pieces of steel hardening, annealing, tempering, and other high temperature heat treatment in laboratories of industrial and mining enterprises, universities, research institutes; can also be used for sintering of metal, stone, ceramic, dissolution analysis of high-temperature heating.
Characteristics:
1. Unique door design, safe and easy door operation, to ensure the high temperature inside that the heat does not leak.
2. High-precision digital display meter, temperature control system with microcomputer chip processor with PID regulation characteristics, time set, temperature difference correction, over-temperature alarm and other functions, high precision temperature control.3. The furnace cavity is baked by the high temperature refractory to ensure durability.4. Excellent door seal to make the heat loss to be minimum, increase the temperature uniformity in the furnace.
Data:
| Model | Voltage(V) | Rated power(kw) | Max temperature(℃) | workroom size(mm) | Overall dimension(cm) | Gross weight(kg) |
| SX-2.5-10 | 220V/50HZ | 2.5 | 1000 | 200*120*80 | 60*37*45 | 65 |
| SX-4-10 | 220V/50HZ | 4 | 1000 | 300*200*120 | 80*57*70 | 120 |
| SX-8-10 | 380V/50HZ | 8 | 1000 | 400*250*160 | 94*64*76 | 186 |
| SX-12-10 | 380V/50HZ | 12 | 1000 | 500*300*200 | 104*74*83 | 262 |
